LU-DTPP4C 4 Heads Peristaltic Pump Liquid Filling Machine
Machine model : LU-DTPP4C
Product ranges
Pro Range
LU-DTPP4C 4 Heads Peristaltic Pump Liquid Filling Machine
Machine model : LU-DTPP4C
- Throughput: 30-50 bottles/min(based on bottles and liquids)
- Format range: 2500 ml/min
- Utilities: 110/220V 50Hz-60Hz 60 W(Each Pump)
Gallery
Machine views
Specifications
Reference details
| Power supply | 110/220V 50Hz-60Hz 60 W(Each Pump) |
|---|---|
| Filling Range | 2500 ml/min |
| Maximum flow | 2500 m/min for each nozzle (based on water ) |
| Filling nozzles | 4(we can customize the nozzles based on your demands) |
| Working speed | 30-50 bottles/min(based on bottles and liquids) |
| Air pressure | 0.3-0.4MPa |
| Filling accuracy | ≤±1% (For water) |
| Diameter of filling nozzle | 6/8mm |
| Delay range | 0.01-999.9s |
| Belt length | 1 m |
| Size of air compressor connector | OD 8 mm |
| Machine model | LU-DTPP4C |
Quick answers
Buyer and engineer notes
What is LU-DTPP4C 4 Heads Peristaltic Pump Liquid Filling Machine used for?
Machine model : LU-DTPP4C
What output can LU-DTPP4C 4 Heads Peristaltic Pump Liquid Filling Machine achieve?
This page lists output at 30-50 bottles/min(based on bottles and liquids). Actual throughput depends on the product, container, fill volume, changeover requirements and overall line setup.
What utilities or site requirements should I plan for?
Power: 110/220V 50Hz-60Hz 60 W(Each Pump); Air pressure: 0.3-0.4MPa; Footprint / size: OD 8 mm
Can Lancing UK help match this machine to my product and container?
Yes. Lancing UK can review your product characteristics, bottle or pack format, closure type, required output and site constraints to confirm the right configuration before supply.
