Pro Range

Automatic Flat Paper Labeling Machine

The Lancing UK LU-TB180PBF is a compact, automatic labeling machine designed for flat paper paging and precise label application. With a labeling speed of up to 260 pieces per minute and ±1mm accuracy, it’s ideal for high-efficiency operations in pharmaceutical, cosmetic, and food industries. The machine supports a wide range of object sizes and label dimensions, and its small footprint makes it perfect for space-conscious production environments. Equipped with a stable conveyor and intelligent control system, it streamlines labeling tasks while maintaining consistent performance. Labeling Machine Specifications – Model LU-TB180PBF Specification Details Model LU-TB180PBF Voltage 220V / 110V, 50–60Hz Power 980W Working Speed 30 pcs/min (labeling machine) Labeling Speed 20–260 pcs/min Labeling Accuracy ±1 mm Suitable Object Length 40–340 mm Suitable Object Width 30–200 mm Suitable Object Thickness 0.2–5 mm Suitable Label Size ≤150 mm (W) Label Roll Inner Diameter Φ75 mm Label Roll Outer Diameter ≤240 mm Conveyor Size Approx. 1100 × 100 mm Machine Size (L×W×H) Approx. 440 × 465 × 630 mm Package Size (L×W×H) Approx. 1130 × 620 × 630 mm Machine Weight 25 kg (labeling unit) + 74 kg (main machine) Package Weight Approx. 129 kg (103 kg + 26 kg)

• Throughput: Configurable (confirm during quote)
• Format range: Formats adjustable (bottle/closure dependent)
• Utilities: Site utilities to be confirmed
