Pro Range

Rotor Pump Paste Filling Machine

The Lancing UK LU-DTGT900U is a high-performance automatic filling machine equipped with a rotor pump and a 100L mixer hopper, ideal for handling viscous products such as pasta sauce, ketchup, and jam. Designed for precision and speed, it supports filling volumes from 5ml to 5000ml with ≤±1% accuracy. The pneumatic bottle positioning system ensures stable and accurate filling, while the 1300r/min rotation speed enables efficient throughput of up to 60 bottles per minute. Built for industrial-grade reliability and ease of operation. Lancing UK LU-DTGT900U Granule Filling Machine – Technical Specifications Parameter Specification Model LU-DTGT900U Recommended Filling Volume 5–5000 ml Filling Accuracy ≤ ±1% Bottle Opening Size Φ > 20 mm Hopper Capacity 100 L Working Speed 10–60 bottles/min (based on 250ml jam) Rotating Speed 1300 r/min Machine Dimensions Approx. 1100 × 630 × 840 mm Package Dimensions Approx. 1205 × 1000 × 1600 mm Package Weight Approx. 260 kg

• Throughput: Configurable (confirm during quote)
• Format range: Formats adjustable (bottle/closure dependent)
• Utilities: Site utilities to be confirmed
