Pro Range

High-Speed Wrap-around Labeling Machine

The Lancing UK LU-TB200R is a high-performance automatic labeling machine designed for cylindrical containers such as bottles, vials, cans, and canisters. Featuring an application belt system, it eliminates the need for format sets, enabling ultra-fast setup and seamless operation. Capable of labeling up to 150 products per minute, it supports partial, full wrap-around, and overlap labeling styles. With adjustable compatibility for bottle diameters from 30–100 mm and label sizes up to 130 mm wide, the TB200R offers precision, speed, and versatility for modern packaging lines. Lancing UK LU-TB200R Automatic Labeling Machine – Technical Specifications Parameter Details Machine Model LU-TB200R Voltage 220V / 110V, 50–60Hz Power Consumption 1200W Labeling Speed Approx. 40–150 bottles/min (depends on bottle and label size) Suitable Bottle Diameter 30–100 mm Suitable Bottle Height 30–200 mm Label Size 15–130 mm (W) × 15–300 mm (L) Label Roll Inner Diameter Φ76 mm Label Roll Outer Diameter Φ350 mm Machine Dimensions Approx. 2005 × 860 × 1355 mm Machine Weight Approx. 200 kg

• Throughput: Configurable (confirm during quote)
• Format range: Formats adjustable (bottle/closure dependent)
• Utilities: Site utilities to be confirmed
