LU-DTDP2 Desktop Liquid Filling Machine
The Lancing UK LU-DTDP2 Desktop CNC Diaphragm Pump Liquid Filling Machine with Conveyor is designed for efficient, precise, and automated liquid filling. Equipped with an infrared sensor, it automatically stops when no bottles are detected, ensuring accuracy and reducing waste. The adjustable conveyor speed allows smooth bottle transfer, while the stainless steel body ensures durability and hygiene. With a digital control panel, intelligent fault detection, and customizable nozzles, this compact machine is ideal for short-run production or integration into a production line. Suitable for filling mineral water, beverages, edible oils, condiments, and daily chemical liquids.
- Throughput: 1500-3000 bottles/hour(depends on botle size and liquid)
- Format range: 0.01-999.9s
- Utilities: 110/220V 50-60HZ
Gallery
Machine views
Specifications
Reference details
| About | 50kg |
|---|---|
| Power Supply Voltage | 110/220V 50-60HZ |
| Power | 250W |
| Maximum flow velocity | 4000m/min (base on water) |
| Working speed | 1500-3000 bottles/hour(depends on botle size and liquid) |
| Air pressure | 0.3-0.4MPa |
| Filling accuracy | ≤+1% (For water) |
| Diameter of Flling Nozzle | 6/8mm |
| Delay Range | 0.01-999.9s |
| Count Range | 1-99999 Times |
| Machine Size | 1350x710x600mm |
| Machine Weight | About 50kg |
| Filling Volume | 3-1000ml(220V)3- 500ml(110V)since the power of 110v machine is not large, so we recommend 3-500ml for each nozzle |
Quick answers
Buyer and engineer notes
What is LU-DTDP2 Desktop Liquid Filling Machine used for?
The Lancing UK LU-DTDP2 Desktop CNC Diaphragm Pump Liquid Filling Machine with Conveyor is designed for efficient, precise, and automated liquid filling. Equipped with an infrared sensor, it automatically stops when no bottles are detected, ensuring accuracy and reducing waste.
What output can LU-DTDP2 Desktop Liquid Filling Machine achieve?
This page lists output at 1500-3000 bottles/hour(depends on botle size and liquid). Actual throughput depends on the product, container, fill volume, changeover requirements and overall line setup.
What utilities or site requirements should I plan for?
Voltage: 110/220V 50-60HZ; Power: 110/220V 50-60HZ; Air pressure: 0.3-0.4MPa
Can Lancing UK help match this machine to my product and container?
Yes. Lancing UK can review your product characteristics, bottle or pack format, closure type, required output and site constraints to confirm the right configuration before supply.
