LU‑GTSM1 Semi‑auto Servo Motor Paste Filling Machine
The Lancing UK LU‑GTSM1 Semi‑automatic Servo Motor Rotor Pump Paste Filling Machine offers exceptional accuracy thanks to its servo motor control system...
Product ranges
Semi Automatic
LU‑GTSM1 Semi‑auto Servo Motor Paste Filling Machine
The Lancing UK LU‑GTSM1 Semi‑automatic Servo Motor Rotor Pump Paste Filling Machine offers exceptional accuracy thanks to its servo motor control system. Filling volume and speed can be easily adjusted via user‑friendly parameter settings, ensuring flexibility for different production needs. Built for versatility, it efficiently handles viscous products such as honey, glue, syrup, and ketchup with a filling accuracy of ≤ ± 0.5 %.
- Throughput: Approx. 10 – 25 bottles/min (depends on bottle size & liquid)
- Format range: Formats adjustable (bottle/closure dependent)
- Utilities: 220 / 110 V, 50 / 60 Hz
Gallery
Machine views
Specifications
Reference details
| Model | LU‑GTSM1 |
|---|---|
| Voltage | 220 / 110 V, 50 / 60 Hz |
| Power | Approx. 950 W |
| Filling Accuracy | ≤ ± 0.5 % |
| Filling Speed | Approx. 10 – 25 bottles/min (depends on bottle size & liquid) |
| Filling Volume | 5 – 100 / 10 – 300 / 50 – 500 / 100 – 1000 ml |
| Equipped Air Pressure | 0.4 – 0.6 MPa |
| Air Consumption | ≥ 0.1 m³/min |
| Machine Size | Approx. 580 × 590 × 1590 mm |
| Machine Weight | Approx. 92 kg |
| Package Size | Approx. 700 × 1520 × 700 mm |
| Package Weight | Approx. 116 kg |
Quick answers
Buyer and engineer notes
What is LU‑GTSM1 Semi‑auto Servo Motor Paste Filling Machine used for?
The Lancing UK LU‑GTSM1 Semi‑automatic Servo Motor Rotor Pump Paste Filling Machine offers exceptional accuracy thanks to its servo motor control system. Filling volume and speed can be easily adjusted via user‑friendly parameter settings, ensuring flexibility for different production needs.
What output can LU‑GTSM1 Semi‑auto Servo Motor Paste Filling Machine achieve?
This page lists output at Approx. 10 – 25 bottles/min (depends on bottle size & liquid). Actual throughput depends on the product, container, fill volume, changeover requirements and overall line setup.
What utilities or site requirements should I plan for?
Voltage: 220 / 110 V, 50 / 60 Hz; Power: Approx. 950 W; Air pressure: 0.4 – 0.6 MPa
Can Lancing UK help match this machine to my product and container?
Yes. Lancing UK can review your product characteristics, bottle or pack format, closure type, required output and site constraints to confirm the right configuration before supply.
