LU-SPL6 Automatic Heat Shrink Tunnel Shrinking Wrapping Machine
This automatic shrink wrap machine combines a side sealing system and heat shrink tunnel into one efficient unit. It automatically feeds POF, PE, or PVC...
Product ranges
Pro Range
LU-SPL6 Automatic Heat Shrink Tunnel Shrinking Wrapping Machine
This automatic shrink wrap machine combines a side sealing system and heat shrink tunnel into one efficient unit. It automatically feeds POF, PE, or PVC shrink film , performs precise side sealing, and delivers a clean, tight package through the shrink tunnel . Ideal for packaging boxes, books, and electronics, this shrink packaging machine boosts productivity and ensures professional packaging results.
- Throughput: 15–30 bag/min
- Format range: 40kg max
- Utilities: 220V 50-60Hz
Gallery
Machine views
Specifications
Reference details
| Model | LU-BF750 |
|---|---|
| Power supply voltage | 220V 50-60Hz |
| Air pressure | 0.5Mpa |
| Power | 2.26Kw |
| Packaging speed | 15–30 bag/min |
| Cutter Size | 870mm × 770 |
| Maximum Package Size | W+H ≤ 700mm, L+H ≤ 800mm, H ≤ 150mm |
| Conveyor Belt Width | 600mm |
| Applicable shrink film | POF/PE |
| Film shrinkage ratio | 60% |
| Table height | 780mm (adjustable) |
| Overall dimensions (L × W × H) | 2350 × 1350 × 1630mm |
| Machine weight | 440kg |
| Conveyor Loading Weight | 15–20kg |
| Voltage | 380V 50/60Hz |
| Carrying capacity | 40kg max |
| Furnace Road Size (mm) | 1800 × 750 × 400mm |
| Outline dimension (mm) | 2100 × 1010 × 1470mm |
| Transporting velocity | 0–15m/min |
Quick answers
Buyer and engineer notes
What is LU-SPL6 Automatic Heat Shrink Tunnel Shrinking Wrapping Machine used for?
This automatic shrink wrap machine combines a side sealing system and heat shrink tunnel into one efficient unit. It automatically feeds POF, PE, or PVC shrink film , performs precise side sealing, and delivers a clean, tight package through the shrink tunnel .
What output can LU-SPL6 Automatic Heat Shrink Tunnel Shrinking Wrapping Machine achieve?
This page lists output at 15–30 bag/min. Actual throughput depends on the product, container, fill volume, changeover requirements and overall line setup.
What utilities or site requirements should I plan for?
Voltage: 220V 50-60Hz; Power: 220V 50-60Hz; Air pressure: 0.5Mpa
Can Lancing UK help match this machine to my product and container?
Yes. Lancing UK can review your product characteristics, bottle or pack format, closure type, required output and site constraints to confirm the right configuration before supply.
